2026 CIMARRON TRAILERS NS4G

Stock# 44480

New 2026 Cimarron NS4G Gooseneck Horse Trailer

Cimarron Norstar aluminum horse trailers are engineered to be durable and safe. Bumper pull or gooseneck configurations ensure effortless towing and comfort.

Model: NS4G

Warranty:

• 8yr- Structural
• 3yr-Body and Hardware

Overall Dimensions

• Box Length: 21' 9"

• Box Width: 6' 10"

• Box Height: 7' 1"

• Gooseneck (GN) Length: 8' 2"

• GN Drop Wall: 53" (for extreme 4x4 clearance)

• GN Structure: Standard Duty

Undercarriage

• GVWR: 12,000 lbs

• Axles: 6,000 lb Dexter Torflex Axles, 8-Bolt Hubs with 1/2" Studs

• Axle Articulation: 10° up

• Brakes: Electric (All Wheel)

• Tires: Goodyear ST 235/80 R16" LR-E

• Wheels: 8-Hole Aluminum, Black Spoke 16"

Design

• Nose Profile: Tapered sides with 18" corners

• Nose Sheet: Polished stainless steel

• Side Walls: Extruded side slat @ stall area (black, mill finished extrusions)

• Sheet Color: Black

• Fenders: Teardrop, overall width 102" O.A.W.

• Roof: Insulated roof panel

Tack Rooms

• Front Tack: Solid partition wall, full height & width, slant wall

• Rear Tack: Folding rear tack wall (60/40 arrangement)

• Mid Tack: 4' 6" length, 3' width

• Closet Tack: 4' 2" LH length, 8' 2" RH length, 6' 10" width

• Floor: Rubber mat floor, carpet GN wall & deck

• Battery: Single battery box aluminum under GN with electric jack

Stall Equipment

• Restraints: 1 chest bar, 1 butt bar

• Padding: 6 pads (chest & sides)

• Dome Lights: Optibrite LED (Qty: 4)

• Bridle Hooks: 6 (set)

• Brush Trays: Qty: 2

• Clothes Bars: Qty: 1

• Pop-Up Vents: Qty: 4

• Saddle Racks: 4 adjustable pads, removable posts (Qty: 2 posts)

• Blanket Poles: 2 (adjustable on saddle rack post)

Special Requirements

• Add recessed paddle latch on side access door

• Rear stall is 1' longer than standard, allowing divider to lay flat

We offer outstanding financing options, accept trades, and can arrange nationwide NO HASSLE delivery!

Inquire today for more information! (888) 333-6613

**We believe these specifications to be accurate. Any discrepancies are unintentional. Please verify information with a sales associate prior to purchase.**
