DAKOTA BP
Steel slant load bumper pull horse trailer with front slant tack room and limited options available
Standard Features
Available Sizes
2-horse, 14' floor length w/2-3500# axles, 15" tires & 6-hole wheels
3-horse, 16' floor length w/2-3500# axles, 15" tires & 6-hole wheels
3-horse, 16' floor length w/2-5200# axles, 15" tires & 6-hole wheels
Dimensions
6'-6" body height
6' or 6'-8" body width
30" tongue length
Undercarriage
Rubber torsion axles with four wheel independent suspension and greasable hubs for easy lubrication
Electric brakes on all wheels
Radial tires on silver modular wheels with chrome center caps
Spare tire rack in tack room
Coupler & Jacks
2-5/16" coupler and safety chains with hooks
Top-wind jack with caster wheel
Emergency breakaway system: switch, cable and battery box complete with battery and charger
Design Features & Hardware
Low profile 6" radius corner galvanneal roof
All steel frame with formed galvanneal panels
Rubber mounted optical window in front
52" sides with air spaces above with plexiglass strap on both sides (plexiglass and rail not standard)
Treated floor
Steel hold backs on front tack door
Drop leg rear gate stop
Greasable exterior hinges
Aluminum tread plate gravel guard on front and fenders
Chrome trim with colored vinyl insert
Pin striping
Tag bracket
Stall Area Equipment
Removable slant tubing dividers with solid head partition
Quick release slam latches on all dividers
One-piece rear door matches sides
Interior and exterior tie rings
Lights
DOT required lighting
Dome lights (one in tack room and one in stall area)
Front Tack Room Equipment
Front slant tack room (tack room size - 0' to 4'-6")
Slant wall between stalls and front tack room
Full front tack door with recessed locking handle located on curb side
Clothes rod in tack room
Four saddle racks on a tree and bridle hooks in tack room
